Ball Socket End Fittings Overview:
Mechanical stress, wind-induced vibrations, and frequent line movement can cause rigid insulator connections to fail prematurely, leading to dropped lines and severe grid outages.
Deploy our specialized Ball Socket End Fittings to absorb kinetic stress and maintain absolute structural integrity:
- Features a precision-engineered spherical contact surface that ensures connection points are always evenly distributed, delivering excellent positioning accuracy without localized wear.
- Forged from high-grade carbon and alloy steel (45# and 40Cr) and coated with a heavy-duty zinc layer (≥86μm) to ensure a highly reliable connection that thrives in occasions of frequent movement and harsh weather.
Key Features & Benefits:
Optimize your high-voltage engineering specifications instantly with these rigorously tested, high-safety advantages:
- Provides exceptional positioning accuracy due to a precise spherical contact surface.
- Ensures a highly reliable connection, perfect for setups experiencing frequent movement.
- Reduces friction resistance significantly, offering a lightweight and flexible operation.
- Supports a massive rated mechanical load capacity reaching up to 160kN.
- Protected by a thick hot-dip galvanized zinc layer (≥86μm) for superior corrosion resistance.
Applications & Use Cases for Ball Socket End Fittings:
Integrate this dynamic transition hardware to establish completely fail-proof electrical and railway distribution networks.
This heavy-duty unit is the definitive engineering choice for the following critical utility tasks:
- Securing high-voltage transmission lines safely using standardized Ball Socket End Fittings.
- Integrating seamlessly with heavy-duty composite and overhead suspension insulators.
- Establishing highly stable, flexible connections across complex railway insulator systems.
Technical Specifications:
Review the exact mechanical loads, voltage compatibilities, and material data below to ensure perfect alignment with your insulator engineering standards.
Ball Head Parameters
| Type | Rated Mechanical Load (kN) | Voltage Level (kV) | Weight (kg) | Material | Zinc Layer Thickness (μm) |
|---|---|---|---|---|---|
| BH50-18-95 | 50 | 10 – 35 | 0.30 | 45# | ≥ 86 |
| BH70-18-105 | 70 | 35 – 110 | 0.33 | 45# | ≥ 86 |
| BH100-18-105 | 100 | 110 – 200 | 0.39 | 45# | ≥ 86 |
| BH120-24-125 | 120 | 110 – 200 | 0.55 | 40Cr | ≥ 86 |
| BH160-24-168 | 160 | 220 – 500 | 0.83 | 40Cr | ≥ 86 |
Ball Socket Parameters
| Type | Rated Mechanical Load (kN) | Voltage Level (kV) | Weight (kg) | Material | Zinc Layer Thickness (μm) |
|---|---|---|---|---|---|
| BS50-18-95 | 50 | 10 – 35 | 0.55 | 45# | ≥ 86 |
| BS70-18-105 | 70 | 35 – 110 | 0.67 | 45# | ≥ 86 |
| BS100-18-105 | 100 | 110 – 200 | 0.77 | 45# | ≥ 86 |
| BS120-24-125 | 120 | 110 – 200 | 0.88 | 40Cr | ≥ 86 |
| BS160-24-168 | 160 | 220 – 500 | 1.65 | 40Cr | ≥ 86 |
