Heavy duty cut out Overview:
Exposed electrical connections are highly vulnerable to unauthorized tampering, physical vandalism, and catastrophic short circuits.
Deploy our structurally tough cutout base to protect your critical junction points safely and efficiently:
- Features a vandal-resistant tough design to completely prevent unauthorized access and severe physical damage.
- Incorporates a convenient slide-fit front cover to ensure maximum ease of jointing for maintenance crews.
Key Features & Benefits:
Optimize your electrical safety installations instantly with these highly reliable, meticulously engineered advantages:
- Engineered with a vandal-resistant tough exterior design.
- Features a slide-fit front cover for ease of jointing.
- Handles a massive 80kA maximum breaking capacity safely.
- Supports a versatile rating range from 40A up to 300A.
- Readily available with convenient free sample testing.
Applications & Use Cases for heavy duty cut out:
Integrate this dynamic protective hardware to establish completely fail-proof electrical distribution networks.
This highly durable base is the definitive safety choice for the following critical industrial tasks:
- Protecting vulnerable street-level electrical connections safely against severe vandalism and tampering.
- Securing high-capacity industrial circuits efficiently using a standardized heavy duty cut out.
- Facilitating rapid grid maintenance and safe cable jointing flawlessly using the slide-fit cover design.
Technical Specifications:
Review the exact electrical ratings and high-capacity breaking limits below to guarantee perfect safety compliance for your network.
| Technical Parameters | |
| Product Model | MC300 HDCO Heavy Duty Cutout Base |
| Current Rating Range | 40A, 50A, 63A, 80A, 100A, 125A, 160A, 200A, 250A, 300A |
| Voltage Rating | 415VAC, 500VAC, 550VAC |
| Breaking Capacity | 80kA |
| Design Feature | Vandal-resistant with slide-fit front cover |
DIMENSION:
