ABC Tension Clamp Product Overview
Engineered for optimal electrical safety, this wedge Type hardware ensures a seamless installation process while maintaining structural integrity across 1kV, 10kV, and 20kV utility lines.
- Built with a streamlined wedge structure that makes it exceptionally easy to install on-site.
- Allows cables to be installed directly without any need for peeling the outer insulation.
- Delivers outstanding insulation performance to prevent electrical faults and ensure line stability.
- Manufactured under a full quality control plan to confirm reliable, long-lasting quality.
ABC Tension Clamp Key Features
Sourcing the Nxjg clamp guarantees certified performance alongside flexible and cost-effective B2B procurement terms:
- Order Flexibility: Zero Minimum Order Quantity (MOQ) on initial purchases, and a low 100-piece threshold for subsequent orders. Free samples are provided (buyer covers freight).
- Project Efficiency: Offers low factory costs, fast quotation responses, and dependable after-sale service.
- Tender & OEM Support: Complete document sets are ready for tender submission, and custom OEM manufacturing requirements are fully accepted.
ABC Tension Clamp Applications
Tailored for robust overhead tensioning, this ABC Tension Clamp provides crucial structural reinforcement. It is strictly used for:
- Fixing and tightening 1kV, 10kV, and 20kV aerial insulated aluminium core wires (JKLYJ terminals).
- Supporting insulation strings directly without wire degradation.
- Fulfilling standard hardware requirements for large-scale low and medium-voltage (LV and MV) EPC material lots.
ABC Tension Clamp Technical Specifications
Review the exact mechanical load parameters and cable diameter specifications for the 1-10KV and 20KV Nxjg series below to ensure strict compatibility with your network.
Specifications for 1-10KV Lines
| Catalog No. | Spec (mm²) | 1KV Cable Dia (mm) | 10KV Cable Dia (mm) | Grip Strength (KN) | Failure Load (KN) |
|---|---|---|---|---|---|
| NXJ-1 | 35 | 9.8 | 15.8 | 3.4 | 7.5 |
| 50 | 11.2 | 17.1 | 4.6 | ||
| NXJ-2 | 70 | 12.8 | 18.8 | 6.7 | 14.5 |
| 95 | 14.8 | 20.4 | 8.9 | ||
| NXJ-3 | 120 | 16.2 | 21.8 | 11.3 | 22.0 |
| 150 | 18.2 | 23.4 | 13.7 | ||
| NXJ-4 | 185 | 20.2 | 25.0 | 17.3 | 36.4 |
| 240 | 22.6 | 27.2 | 22.5 |
Specifications for 20KV Lines
| Catalog No. | Spec (mm²) | 20KV Cable Dia (mm) | Grip Strength (KN) | Failure Load (KN) |
|---|---|---|---|---|
| NXJ-3 | 35 | 19.2 | 3.4 | 10.8 |
| 50 | 20.5 | 4.6 | ||
| 70 | 22.0 | 6.4 | ||
| NXJ-4 | 95 | 23.7 | 8.9 | 22.1 |
| 120 | 25.2 | 11.3 | ||
| 150 | 26.7 | 13.7 | ||
| NXJ-5 | 185 | 28.3 | 17.3 | 45.5 |
| 240 | 30.6 | 22.5 | ||
| 300 | 32.8 | 28.2 |
