JBC Connector Product Overview:
Acting as an essential upgrade from traditional line taps, the JBC connector simplifies outdoor branch splicing while maintaining consistent piercing pressure.
Engineered to keep a continuous electrical connection without causing damage to the core lead, this hardware integrates the following operational mechanics:
- Zero Stripping Required: The specialized internal teeth penetrate the cable jacket instantly upon tightening, drastically cutting down installation time.
- Universal Compatibility: Employs a specialized connecting tablet designed to flawlessly join Copper to Copper, Aluminum to Aluminum, or Copper to Aluminum.
- Commercial Scalability: Supported by a massive manufacturing output, offering zero MOQ on initial orders and complete documentation for utility tenders.
Key Features & Benefits of the JBC Connector:
Upgrading your network with this piercing hardware significantly extends the lifespan of insulated overhead leads. The unique arc surface design accommodates an massive connection scope ranging from 0.75mm² up to 400mm².
Utility procurement teams gain immediate structural and financial advantages through these precise engineering traits:
- Absolute Weatherproofing: The self-seam frame is totally waterproof, moisture-proof, and anti-corrosive, preventing galvanic decay.
- High Dielectric Strength: The insulated case body actively resists UV illumination and environmental aging, supporting insulation strength up to 12KV.
- Optimal Conductivity: Features incredibly low electrical resistance, measuring less than 1.1 times the resistance of a branch conductor of the exact same length.
- Certified Production: Fabricated in facilities strictly governed by ISO 9001, ISO 14001, and ISO 18001 quality control frameworks.
JBC Connector Applications & Use Cases:
Designed for robust outdoor performance, the JBC connector serves as the go-to splicing solution for modernizing overhead power distribution.
Utility engineers rely on this specific hardware to execute faultless connections across various demanding field scenarios:
- Creating fast, stripped-free branch lines directly on existing low voltage and medium voltage distribution networks.
- Safely joining conductors of the same or completely different diameters in highly corrosive or wet environments.
- Large-scale EPC material deployments demanding rapid installation without causing extended power interruptions.
- Projects requiring custom OEM manufacturing backed by fast quotations and highly dependable after-sale service.
JBC Connector Technical Specifications:
Review the diverse model ranges and applicable wire cross-sections below to verify that the JBC connector matches your specific grid expansion requirements.
Piercing Connector Technical Data:
| Model Type | Main Line Section (mm²) | Branch Line Section (mm²) | Bolt No. (pcs) |
|---|---|---|---|
| JBC-0 | 25 – 70 | 6 – 35 | 1 |
| JBC-1 | 35 – 70 | 6 – 35 | 1 |
| JBC-2 | 35 – 150 | 35 – 150 | 1 |
| JBC-3 | 50 – 240 | 50 – 240 | 2 |
| CT1 | 25 – 70 | 6 – 35 | 1 |
| CT2 | 25 – 95 | 6 – 25 | 1 |
| DZ3 | 25 – 95 | 25 – 95 | 2 |
